HDMI® Transmission

HDMI® Extender

Filter

More

SC&T HDMI Extender series features models that use different transmission technologies and cables.

‍HDMI over CatX

HDMI over Cat5e, HDMI over Cat6 or higher extenders, and HDMI wall-plate extenders.

HDBaseT HDMI Extender

Use an HDBaseT transmitter to send audio/video, Ethernet, control signals, and USB simultaneously, ideal for data transfer, remote surveillance, and KVM. SC&T HDBT extenders range from HDBaseT 2.0 to HDBaseT 3.0, tailored to your needs.

HDMI over IP Extender

With HDMI over Ethernet technology, you can use a network switch to easily split and switch the extended HDMI source. Use Daisy-chain models for video displays in large venues, cruise ships, and more.

HDMI over Fiber

Use fiber to transmit long-range HDMI signals. SC&T HDMI fiber extenders come in compact and professional versions. Use single-mode optical fiber with SFP+ module to reach a maximum of 60 km.

HDMI over Coax

Transmit HDMI over coaxial cables without replacing the old coaxial cables with Ethernet cables.HDMI Repeater - Stabilize HDMI signals and reduce signal attenuation and interference with HDMI signal repeaters.

Hide

Thank you! Your submission has been received!

Oops! Something went wrong while submitting the form.

4K 60Hz HDMI KVM CAT6 Extender 100M

4K 60Hz HDMI® KVM Extender with USB 2.0

HE02U-4K6G

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A 1 x HDMI Type A Loop

Feature

Resolution up to 4096/ 3840 x2160@60Hz 4:4:4.
Signal extension up to 100m for 4096 x 2160@60Hz.

4K 60Hz Chainable HDMI Repeater/ Extender

4K 60Hz Chainable HDMI Repeater/ Extender

HR01-4K6G

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resolution up to 4K@60Hz 4:4:4.
Signal extension up to 20M.

4 x 4 HDMI (HDBaseT)CAT5e Matrix Switcher

4 x 4 HDMI (HDBaseT)CAT5e Matrix Switcher

HE04M

Video Input

4 x HDMI Type A

Video Output

4 x HDMI Type A

Feature

Resolution up to 1080p@60Hz.
Signal extension up to 100 meters over CAT5e/6.

4K 10 x 10 HDMI (HDBaseT)CAT5e Matrix Switcher

4K 10 x 10 HDMI (HDBaseT)CAT5e Matrix Switcher

HE10M

Video Input

8 x HDMI Type A 2 x HDBaseT

Video Output

2 x HDMI Type A 8 x HDBaseT

Feature

Resolution up to 4K@30Hz.</li><li>Signal extension up to 100 meters over CAT5e/6.
Built-in 2 HDMI local loop-out ports and 8 HDBaseT RJ45 ports.

HDMI Repeater

HDMI Repeater

HR01

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resolution up to 1080p@60Hz.
Signal extension up to 50 meters over HDMI cable.

4K60Hz HDMI KVM Extender over Cat5e/Fiber

4K60Hz HDMI® KVM & USB, RS232, IR, Audio over IP Extender 100M/60KM

HKM01-4K6G

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A 1 x HDMI Type A Loop

Feature

Resolution up to 4K60Hz 4:4:4.
Signal extension up to 100M.

4K HDMI Extender Splitter HDMI over Ethernet/IP

4K60Hz HDMI® CAT6 Extender with HDMI® Loop Out 100M

HE03-4K6G

Feature

Resolution up to 4K60Hz 4:4:4
Signal extension up to 100M

4K HDMI Extender Splitter, Daisy-Chain HDMI Extender Receiver

4K60Hz HDMI® CAT6 Extending Distributor with Chainable Receiver 100M

HE03L-4K6G

Feature

Resolution up to 4K60Hz 4:4:4
Signal extension up to 100M

4K60Hz HDMI KVM & USB, RS232, IR, Audio over IP Extender

4K60Hz HDMI® KVM & USB, RS232, IR, Audio over IP Extender

HKM02B-4K6G

Feature

Resolution up to 4K60Hz 4:4:4.
Signal extension up to 100m over CAT5e (or greater), 60km over fiber optic cable

4K VGA/HDMI Auto-Switching & IR/RS232/POH HDBaseT Extender 70M

4K VGA/HDMI Auto-Switching & IR/RS232/POH HDBaseT Extender 70M

VHE02EIP

Video Input

1 x HDMI Type A 1 x VGA 15-Pin D-Sub

Video Output

1 x HDMI Type A

Feature

Resolution up to 1920x1200@60Hz for VGA. 4K@30Hz for HDMI.
Signal extension up to 70M over CAT5e (or greater) cable.

1 x 4 HDMI Distribution Amplifier CAT5e Extender Kit

1 x 4 HDMI Distribution Amplifier CAT5e Extender Kit

HE04SEK

Video Input

1 x HDMI Type A

Video Output

4 x HDMI Type A 1 x HDMI Type A Loop

Feature

Resolution up to 1080p@60Hz.
Extends and splits up to 4 HDMI signals for up to 70M.

4K HDMI Extender over Fiber KVM IR/RS232

4K60Hz HDMI & USB/IR/RS232 KVM Fiber Optic Extender

HE01F-4K6G

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resolution up to 4K@60Hz 4:4:4.
Signal extension up to 60KM over fiber optic cable.

HDMI over Coaxial Extender, HDMI to Coaxial Converter

HDMI over Coaxial Extender 1080p 100M

HE01C

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A 1 x 75Ω BNC

Feature

Resolution up to 1080p.
Signal extension up to 100M over coaxial cable.

4K 30Hz HDMI to Fiber Extender 1KM Dongle

Compact 4K HDMI® Fiber Extender 1KM

HE01F-4K

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resolution up to 4K30Hz.
Transmission distance up to 1KM over single-mode fibers, 300m over multi-mode fibers.

HDMI CAT5e Extender-Single CAT5e cable 1080p

HDMI® CAT5e Extender-Single CAT5e cable 1080p

HE01ERK

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resolution up to 1080p.
Singal extension up to 70M.

4K 30Hz HDMI/ Display Port/ USB-C Switching Extender

4K 30Hz HDMI/ Display Port/ USB-C Switching Extender

HUE03-4K

Video Input

1 x HDMI Type A 1 x DisplayPort 1 x USB-C

Video Output

1 x HDMI Type A

Feature

Resolution up to 4K@30Hz 4:4:4.
Signal extension up to 150M over CAT5e cable.

HDMI CAT5e Extender-Single CAT5e cable 1080p 40M

HDMI CAT5e Extender-Single CAT5e cable 1080p 40M

HE01SE

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resolution up to 1080p@60Hz.
Signal extension up to 40M at 1080p over CAT5e; 45M over CAT6.

4K HDMI & IR CAT5e Extender 70M

4K HDMI & IR CAT5e Extender 40M

HE02EI

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resolution up to 4K@30Hz 4:4:4, 40m
1080p signal extension up to 70M over CAT5e/6 cable.

HDMI CAT5e Extender-Single CAT5e cable 1080p 50M

HDMI CAT5e Extender-Single CAT5e cable 1080p 50M

HE01S

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resolution up to 1080p@60Hz.
Signal extension up to 50M over CAT5e cable.

4K HDMI USB/Audio/RS232/IR CAT5e KVM Extender 140M with Fiber

4K HDMI USB/Audio/RS232/IR CAT5e KVM Extender 140M with Fiber

HKM01-4K

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A 1 x HDMI Type A Loop

Feature

Resolutions up to 4K 30Hz 4:4:4.
Signal extension up to 120M over CAT5e, 140M over CAT6, 60KM over single mode fiber

HDMI & IR CAT5e Extender 1080p 40M

HDMI & IR CAT5e Extender 1080p 40M

HE01SI

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resolution up to 1080p@60Hz.
Signal extension up to 70M over CAT5e cable.

4K HDMI HDBaseT Extender - Uncompressed HDMI Up to 100M

4K HDMI CAT5e Extender 100M

HE02E

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resolution up to 4K@30Hz 4:4:4.
Signal extension up to 100M over CAT5e or greater cable.

HDMI & USB Keyboard Mouse CAT5e Extender 1080p 150M

HDMI® & USB Keyboard Mouse CAT5e Extender 1080p 150M

HKM01E

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A 1 x HDMI Type A Loop

Feature

Resolutions up to 1080p@60Hz & 1920 x 1200.
Signal extension up 160M over CAT6.

4K@30 HDMI Extender over CAT6, HDMI Extender Splitter

4K HDMI® CAT5e/6 Extender CAT5e 120M/CAT6 140M

HE03-4K

Video Input

1 x HDMI Type A

Video Output

HDMI Type A

Feature

Resolution up to 4K@30Hz 4:4:4.
Signal extension up to 120M over CAT5e, 140M over CAT6.

HDMI CAT5e Extender with Chainable Receiver

HDMI CAT5e Extender with Chainable Receiver

HE01SL

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A 1 x RJ45 Loop

Feature

Resolution up to 1080p@60Hz.
Signal extension up to 70M over CAT5e (or greater) cable.

Wall Plate HDMI & IR Repeater over CAT5e Extender HW01

Wall Plate HDMI & IR Repeater over CAT5e Extender

HW01

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resoluiton up to 1080p@60Hz.
Signal extension up to 60M over two CAT5e (or greater) cables.

4K HDMI Extender over CAT6, HDMI Daisy Chain Receiver

4K HDMI CAT5e/6 Extender with Chainable Receiver

HE03L-4K

Video Input

1 x HDMI Type A

Video Output

HDMI Type A

Feature

Resolution up to 4K@30Hz 4:4:4.
Signal extension up to 120M over CAT5e, 140M over CAT6.

Wall Plate HDMI & IR Repeater over CAT5e Extender HW02

Wall Plate HDMI™ & IR Repeater over CAT5e Extender

HW02

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resoluiton up to 1080p@60Hz.
Signal extension up to 60M over two CAT5e (or greater) cables.

4K 60Hz 4:4:4 HDMI & IR/R232 CAT5e Extender 70M

4K 60Hz 4:4:4 HDMI & IR/R232 CAT5e Extender 70M

HE02EIX

Video Input

1 x HDMI Type A

Video Output

2 x HDMI Type A 1 x HDMI Type A Loop

Feature

Resolution up to 4K@60hz 4:4:4.
Signal extension up to 70M over CAT5e or greater cable.

HDMI over Cat6/Ethernet Extender Splitter 1080P

HDMI CAT5e Extender with HDMI Loop Out 150M

HE03

Video Input

1 x HDMI Type A

Video Output

HDMI Type A

Feature

Resolution up to 1080p@60Hz.
Signal extension up to 150M over CAT5e (or greater) cable.

4K 60Hz 4:4:4 HDMI & IR/R232 CAT5e Extender 100M

4K 60Hz HDMI & IR/R232 CAT5e Extender 100M

HE02EX

Video Input

1 x HDMI Type A

2 x HDMI Type A 1 x HDMI Type A Loop

Feature

Resolution up to 4K@60Hz 4:4:4, 100M.
Signal extension up to 70M over Cat5e/6 cable.

4K 60Hz 4:4:4 HDMI & IR/R232/POH CAT5e Extender 70M

4K 60Hz HDMI & IR/R232/POH CAT5e Extender 40M

HE02EIXP

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resolution up to 4K@60Hz 4:4:4, 40m
Signal extension up to 70m, 1080p.

4K 60Hz 4:4:4 HDMI & IR / RS232 / POH CAT5e Extender 70M

4K 60Hz HDMI & IR / RS232 / POH CAT5e Extender 70M

HE02EXP

Video Input

1 x HDMI Type A

Video Output

1 x HDMI Type A

Feature

Resolution up to 4K@60Hz 4:4:4, 70M.
Signal extension up to 90M, 1080p over Cat6a(or greater) cable.
