SP009T

UTP HD-TVI/AHD/HDCVI/CVBS Surge Protector

  • Supports HD-TVI, HDCVI, AHD signals video formats.
  • Built-in a 2-pin terminal block at each end.
  • Response time less than 1 ns.
Inquiry

As a manufacturer, we value the profit of our clients and do not have any online store. You can get the unpublished price from us through the inquiry button.

SEE other models
Inquiry

SP009T is a surge protector designed to protect HD-TVI, AHD, HDCVI, CVBS devices from high voltage surges.

Do not use a surge protector that you think works, use one that already works

We're from the Country with a High Density of Lightning

Taiwan is located in a tropical region and has a relatively high density of lightning (174.7 stikes per km²). On the other hand, The state in the region that has the highest lightning density in the USA is Florida, only averaging 75.1 strikes per km². The higher the density of lightning, the higher possibility gets equipment damaged by surges. You can also check out the lightning events in your area HERE.

UTP HD-TVI/AHD/HDCVI/CVBS Surge Protector

SP009T

To address the issue, we develop high-standard surge protectors, SP009T, to prevent devices from high voltage surges. Supporting HD-TVI, AHD, HDCVI, and CVBS signals to be compliant with any CCTV camera maker's standard, SP009T has built-in terminal blocks for easy wiring and has addressed thousands of lightning issues for government and commercial projects around the globe.

Can Use in

Features

1 ns Response Time

With 1 nanosecond response time, SP009T can effectively prevent your equipment from high voltage surge before it strikes your CCTV system.

IEC 61000-4-5 Compliant

Supports 2000 amps, 6,000 volts for lightning protection, compliant with IEC 61000-4-5 standard to resist surges caused by overvoltages from switching and lightning transients.

0.8dB Insertion Loss

The low insertion loss allows the CCTV video to maintain good, even though compromising little picture quality.

Related Items

HD-TVI/AHD/HDCVI/CVBS Surge Protector

IP/ PoE Surge Protector

Model

HKM02BP-4K

HKM02B-4K

HKM02B

VDKM02B

Video Format

HDMI

HDMI

HDMI

VGA/DVI

Resolution

4K@30Hz

4K@30Hz

1080p@60Hz

1080p@60Hz

Audio Embed & Extract

V

V

V

V

IR

V

V

V

V

RS232

V

V

V

V

PoE

V

Fiber Module

V

V

  • Supports HD-TVI, HDCVI, AHD signals video formats.
  • Built-in a 2-pin terminal block at each end.
  • Response time less than 1 ns.
Firmware/Software

Release Date

Ver.

Release Note

File Name

No items found.
Tutorial Video

Show More
icon

Specification

ITEM NO.

SP009T

Support

Compliance

IEC 61000-4-5

Response Time

Less than 1ns

Lightning Protection

2KA (8/20μs)/6KV (8/20μs)

Insertion Loss

0.8db @ 42 MHz

Max. Discharge Current

15 KA (Max)

Max. Clamping Voltage

25V

Starting Voltage Surge

6V

Ports & Interfaces

Equipment End

1 x 2-pin Terminal

Cable End

1 x 2-pin Terminal
