UE02H

USB 2.0 CAT5e Extender 140M

  • Extends an USB signal over an Ethernet cable.
  • Signal extension up to 140M.
  • Built-in 4 USB ports at Rx unit.
Inquiry

As a manufacturer, we value the profit of our clients and do not have any online store. You can get the unpublished price from us through the inquiry button.

SEE other models
Inquiry

UE02H is a 4 port USB 2.0 extender designed to carry 4 USB signals to control remote USB devices using a cost-effective Ethernet cable (CAT5e, CAT6, CAT7). It is a perfect solution for digital signage, home network integration, and industrial control.

140M Professional 4-Port USB 2.0 Extender

USB transmissions are often close to the computer unit due to the length of the USB cable. When the cable cannot reach the peripherals, a USB extender is needed to connect USB devices such as a keyboard, mouse, webcam, SSD, etc. UE02H is a USB 2.0 extender over ethernet cables that extends USB signal for 140m, workable with a USB repeater to reach a longer distance. Such USB extension devices help extend the connection between your remote and local devices and make the control more convenient.

How a USB Extender Works

The installation of peripherals and USB devices varies, depending on the user's needs. A USB extender is ideal for different projects, control, and connectivity needs, such as:

Connection Between Existing Devices

The existing computer unit is located in the server room and the USB device are fixed in the space for use. With a USB extender, ethernet cables can be used to connect the devices in separate spaces.

Connect to Remote Devices

Connect to the USB devices located in the equipment room and use them remotely from your office. A USB extender helps to extend the distance between the USB devices and the computer unit in your office.

Connect to Local Devices

You can bring your portable computer/device to the space equipped with fixed USB devices and connect them via a USB extender. A USB extender helps to extend the connection between your portable devices and local USB peripherals.

Quality of the Extender Determines Your Experience

A poor-quality USB extender may lead to a second installation or replacement of devices. Some of the common problems include:

Delay

Efficiency may be compromised when you are using USB devices: cameras, mouses, keyboards, etc.

Interruptions

Devices may become unusable.

Compatibility Issues

Inconvenience due to the unsupported equipment.

Vulnerable

Inadequate surge protection components make the extender susceptible to damage from the surge in power supplies.

Stable USB Extension Solutions with Multiple Choices

SC&T's USB extension devices are all designed and made in Taiwan with consistent quality. You can choose the device best suits your requirements and project needs.

Long-Range USB Ethernet Extender

UE02H is a USB extender that supports USB 2.0 and can extend 4 USB signals up to 140m. It is suitable for use in various conference spaces, industrial and medical environments, etc.

UE02H

USB Over Long Distance

UE02H is a USB extender over ethernet that extends the USB signal for 120m with CAT5e network routing and 140m with CAT6 (or above).

4-Port USB 2.0 Interface

When you need to connect touch panels, webcams, microphones, printers, and external hard drives, USB 2.0 and better can achieve a higher data transfer rate. UE02H has 4 ports USB 2.0 interface for you to connect your keyboard, mouse, and other USB devices.

No Visible Delay

Use UE02H to control your device without visible delay. Our USB extender offers a smooth experience for USB remote control.

USB Power Supply Specifications

The power supply of USB 2.0 ports is standard 5V/500mA. You can use a DC5V 3000mA adapter for a 500mA power supply from each USB 2.0 port.

Plug and Play

UE02H needs neither drivers nor additional configuration on your computer device.

Note: Your USB device may still need to be set up.

Solve Your Power Supply Problem

The Tx side will be powered by your device, while only the Rx, which is connected to a USB device, will require an external power supply for your field setup.

Need a Longer Extension?

If you need to extend the USB 2.0 signal even further, you can use SR01X Network Repeater, which adds another 120m to the distance with each one in the series. With a bandwidth of up to 1000Mbps and a built-in surge protector, it provides stable signal transmission.

Medium Distance, Economical USB Extensions

Also Need to Extend Audio and Video?

If your computer is more than 10m away from the display, you will need an HDMI extender to transmit audio and video signals.

4K 60Hz HDMI Extenders

HE02EX

4K 60Hz 4:4:4 HDMI & IR/R232 CAT5e Extender

  • Resolution 4K@60Hz 4:4:4.
  • 70m over CAT5e/6, 100m over CAT6a.
  • Built-in local loop out.
  • Built-in dual HDMI outputs.
  • Supports bi-directional IR, RS232 transmission.
  • Support CEC, EDID.

HE02EIXP

4K 60Hz 4:4:4 HDMI & IR/R232/POH CAT5e Extender 70M

  • Resolution 4K@60Hz 4:4:4: extension distance up to 40M.
  • Resolution 1080p@60Hz: extension distance up to 70M.
  • Supports PoH (Power over HDBaseT).
  • Supports bi-directional IR, RS232 transmission.
  • Support CEC, EDID.

Model

HKM02BP-4K

HKM02B-4K

HKM02B

VDKM02B

Video Format

HDMI

HDMI

HDMI

VGA/DVI

Resolution

4K@30Hz

4K@30Hz

1080p@60Hz

1080p@60Hz

Audio Embed & Extract

V

V

V

V

IR

V

V

V

V

RS232

V

V

V

V

PoE

V

Fiber Module

V

V

  • Extends an USB signal over an Ethernet cable.
  • Signal extension up to 140M.
  • Built-in 4 USB ports at Rx unit.
(1) Connects UE02HT and UE02HR Directly

(2) Works with optional model SR01 for extra 140M over CAT6 cable, 120M over CAT5e cable
Firmware/Software

Release Date

Ver.

Release Note

File Name

July 13, 2022

V1.0_2207131

Firmware Upgrade
icon

Release Date

July 13, 2022

Ver.

V1.0_2207131

Firmware Upgrade
icon

July 13, 2022

V1.0_2207131

Firmware Upgrade
icon

Release Date

July 13, 2022

Ver.

V1.0_2207131

Firmware Upgrade
icon

July 6, 2020

V1.0_2007061

Firmware Upgrade
icon

Release Date

July 6, 2020

Ver.

V1.0_2007061

Firmware Upgrade
icon

July 6, 2020

V1.0_2007061

Firmware Upgrade
icon

Release Date

July 6, 2020

Ver.

V1.0_2007061

Firmware Upgrade
icon
Tutorial Video

Show More
icon

Specification

ITEM NO.

UE02T

UE02R

Support

Compliance

USB 2.0, USB 1.1, USB 1.0

Data Bandwidth

120 Mbps

Max. Transmission Distance

140M over CAT6, 120M over CAT5e

Ports & Interfaces

Data Input

1 x USB Type B

1 x RJ45

Data Output

1 x RJ45

4 x USB Type A

Show More
