HS04M-4K6G

4K 60Hz 4 in 4 out HDMI Matrix Switcher with Audio Extractor

  • Resolution up to 4K@60hz 4:4:4
  • Built in RS232 console port for remote control or firmware update.
  • Supports auto-scan function, automatically switch to the next avaliable input when the selected one is unable to display.
  • Supports auto switching function, automatically swtich to the last connected input source.
  • li>Managed via front panel buttons, IR remote, RS232.
Inquiry

As a manufacturer, we value the profit of our clients and do not have any online store. You can get the unpublished price from us through the inquiry button.

SEE other models

High-quality Video

Providing high-performance routing systems for 4K digital video and multi-channel audio.

Audio Integration

Extract audio from the HDMI signal and integrate it with your high-end audio amplifier/ speaker.

EDID Management

A variety of EDID options to choose from, making video pictures as perfect as they can.

Inquiry

HS04M-4K6G is a 4 input 4 output HDMI matrix switch that can route 4 Hi-res HDMI videos to 4 HDMI displays. It also has the audio extraction function, allowing you to integrate with your existing premium audio equipment to have a superior audiovisual experience. With all the powerful features, you can have multiple options to control and manage the matrix, depending on your needs. Such as an IR remote, RS232 commands, front panel buttons, Web GUI, Telnet, and Android/ iOS mobile APP.

Model

HKM02BP-4K

HKM02B-4K

HKM02B

VDKM02B

Video Format

HDMI

HDMI

HDMI

VGA/DVI

Resolution

4K@30Hz

4K@30Hz

1080p@60Hz

1080p@60Hz

Audio Embed & Extract

V

V

V

V

IR

V

V

V

V

RS232

V

V

V

V

PoE

V

Fiber Module

V

V

  • Resolution up to 4K@60Hz 4:4:4.
  • Supports ARC (Audio Return Channel).
  • Supports HDMI audio extraction via S/PDIF coaxial output.
  • Supports cable locks on each HDMI input & output port.
  • Built-in LCM panel and LED indications for the status of all connected devices.
  • Rack-mountable (1U standard).
  • Managed via RS232, front panel buttons, IR remote, WebGUI,  iOS/Android APP.
Firmware/Software

Release Date

Ver.

Release Note

File Name

June 4, 2024

V1.0_2406041

Firmware Update
icon

Release Date

June 4, 2024

Ver.

V1.0_2406041

Firmware Update
icon

November 15, 2021

V1.0_2111151

Firmware Upgrade
icon

Release Date

November 15, 2021

Ver.

V1.0_2111151

Firmware Upgrade
icon

July 16, 2021

V1.0_2107162

Firmware Upgrade
icon

Release Date

July 16, 2021

Ver.

V1.0_2107162

Firmware Upgrade
icon
Tutorial Video

Show More
icon

Specification

ITEM NO.

HS04M-4K6G

Support

Compliance

HDMI 2.0, HDCP 2.2, DVI, 3D, HDR, Dolby Vision

Max. HDMI Resolution

4K@60Hz 4:4:4

Video Bandwidth

18 Gbps

Audio Format

LPCM 7.1@192KHz, Dolby TrueHD, DTS-HD MA

RS232 Baud Rate

9600bps

IR Support

45°, 5M

Ports & Interfaces

Video Input

4 x HDMI Type A

Video Output

4 x HDMI Type A

Audio Output

4 x SPDIF

Ethernet Interface

1 x RJ45

RS232 Interface (Console)

1 x DB9 Female

IR Interface

1 x (3.5mm) Phone Jack
