HS42M-4K6G

4K 60Hz 4 in 2 out HDMI Matrix Switcher with Audio Extractor & Scaler

  • Resolution up to 4K@60Hz 4:4:4.
  • Supports HDMI matrix, distribution, separation (combine video from OUTPUT A with audio from OUTPUT B) modes.
  • Built-in optical audio & LPCM audio interfaces.
  • Built in IR sensor and 3.5mm phone jack for external IR receiver cable.
  • Supports resolution up/ down scaling function, 1080p to 4K or 1080p to 4K.
Inquiry

As a manufacturer, we value the profit of our clients and do not have any online store. You can get the unpublished price from us through the inquiry button.

SEE other models

High-quality Video

Providing high-performance routing systems for 4K digital video and multi-channel audio.

Audio Integration

Extract audio from the HDMI signal and integrate it with your high-end audio amplifier/ speaker.

EDID Management

A variety of EDID options to choose from, making video pictures as perfect as they can.

Inquiry

HS42M-4K6G is a 4 input 2 output HDMI matrix switch that allows you to route any 4 Hi-res HDMI videos to any 2 HDMI displays. It not only supports 4K60Hz 4:4:4 resolution but LPCM 7.1@192KHz, Dolby TrueHD, DTS-HD MA audio. It also supports ARC and the audio extraction function, making the integration of your HDMI source with an advanced audio system easy and hassle-free. Moreover, the matrix has a built-in video scaler function that can upscale the 1080p resolution to 4K, or down-scale the 4K to 1080p to connect a legacy display — allowing every connected display to show the best resolution it can support. With all the powerful features, you can intuitively control and manage the matrix switcher via an IR remote, RS232 commands, and the front panel buttons, depending on different requirements.

Model

HKM02BP-4K

HKM02B-4K

HKM02B

VDKM02B

Video Format

HDMI

HDMI

HDMI

VGA/DVI

Resolution

4K@30Hz

4K@30Hz

1080p@60Hz

1080p@60Hz

Audio Embed & Extract

V

V

V

V

IR

V

V

V

V

RS232

V

V

V

V

PoE

V

Fiber Module

V

V

  • Resolution up to 4K@60Hz 4:4:4.
  • Supports HDMI matrix, distribution, separation (combine video from OUTPUT A with audio from OUTPUT B) modes.
  • Built-in optical audio & LPCM audio interfaces.
  • Built-in IR sensor and 3.5mm phone jack for external IR receiver cable for remote control.
  • Supports up/ down scaling function, 4K to 1080p or 1080p to 4K.
  • Supports chroma resampling conversion function, 4:4:4 to 4:2:0.
  • Supports ARC(Audio Return Channel) function.
  • Supports OSD (on screen display).
  • Supports CEC pass-through.
  • Panel LED brightness adjustable.
  • Managed via RS232, IR remote, and front panel buttons.
Firmware/Software

Release Date

Ver.

Release Note

File Name

July 4, 2024

V1.1_2407041

Firmware Update
icon

Release Date

July 4, 2024

Ver.

V1.1_2407041

Firmware Update
icon

October 25, 2023

V1.0_2310251

Firmware Upgrade
icon

Release Date

October 25, 2023

Ver.

V1.0_2310251

Firmware Upgrade
icon

June 15, 2022

V1.0_2206151

Firmware Upgrade
icon

Release Date

June 15, 2022

Ver.

V1.0_2206151

Firmware Upgrade
icon

September 10, 2021

V1.0_2109101

Firmware Upgrade
icon

Release Date

September 10, 2021

Ver.

V1.0_2109101

Firmware Upgrade
icon

September 18, 2020

V1.0_2009181

Firmware Upgrade
icon

Release Date

September 18, 2020

Ver.

V1.0_2009181

Firmware Upgrade
icon
Tutorial Video

Show More
icon

Specification

ITEM NO.

HS42M-4K6G

Support

Compliance

HDMI 2.0, HDCP 2.2, HDCP 1.4, 3D, HDR, CEC

Max. HDMI Resolution

4K@60Hz 4:4:4

Video Bandwidth

18 Gbps

Audio Format

LPCM 7.1@192KHz, Dolby TrueHD, DTS-HD MA

RS232 Baud Rate

9600 bps

IR Support

45°, 5M

Ports & Interfaces

Video Input

4 x HDMI Type A

Video Output

2 x HDMI Type A

Digital Audio Output

1 x TOSLINK

Analog Audio Output

2 x RCA Jack

RS232 Interface

1 x DB9 (Female)

IR Interface

1 x 3.5mm Phone Jack

Power Interface

1 x (5.5 x 2.5mm) DC Jack
