HS10M-4K6G

4K 60Hz 10 in 10 out HDMI Matrix Switcher with Audio Extractor

  • Resolution up to 4K@60hz 4:4:4
  • Supports ARC (Audio Return Channel).
  • Supports HDMI audio extraction via S/PDIF coaxial output.
  • Supports cable locks on each HDMI input & output ports.
  • Built-in LCM panel and LED indications for the status of all connected devices.
Inquiry

As a manufacturer, we value the profit of our clients and do not have any online store. You can get the unpublished price from us through the inquiry button.

SEE other models
4K resolution.

High-Quality Video

High-performance routing of 4K video and multi-channel audio.

Audio extraction.

Audio Integration

Extracts audio from the HDMI source to your high-end audio amplifier.

EDID management.

EDID Management

Different resolutions to choose from; provides perfect video pictures.

Inquiry

HS10M-4K6G is a 10-in-10-out HDMI matrix switch that can route 10 Hi-res HDMI videos to 10 HDMI displays. Moreover, the built-in audio extraction function allows you to integrate with your premium audio equipment for a superior audiovisual experience. With all the powerful features, you have multiple ways to control and manage the matrix depending on your needs. Such as an IR remote, RS232 commands, front panel buttons, Web GUI, Telnet, and Android/iOS mobile APP.

4K 10 in 10 out HDMI Matrix Switcher for Your Professional Projects

HDMI matrix routing videos to multiple screens.

HS10M-4K6G can put 4K 60Hz 4:4:4 HDMI videos, such as PCs, game consoles, Blu-ray players, on hi-resolution PC monitors, TVs, and projectors. The input/ output distance can typically reach up to 35 feet but you can double the distance using HR01-4K6G (HDMI Repeater), which makes it applicable in large spaces like conference rooms, banks, sports bars, and control centers.

Application

HDMI matrix application: Bank surveillance system.

Distance

  • Maximum input cable distance: ~25 feet AWG22 HDMI 1.4 high-speed cable
  • Maximum output cable distance: ~35 feet AWG22 HDMI 1.4 high-speed cable
  • Maximum output 4K cable distance: ~25 feet AWG24 HDMI 2.0 high-speed cable

To reach further distance, please refer to HR01-4K6G.

Features

Control via RS232, IR, web GUI, front panel, Telnet, and apps.

Intuitive Controls

Can be controlled via IR remote, RS232 commands, Web GUI, Telnet, front panel buttons, and Android/ iOS mobile APP. It's built for not only A/V professionals but people with little understanding of technology.

EDID management.

EDID Management

Multiple resolutions can be chosen from, with the EDID copy function that allows hi-res videos to be properly displayed on any HDMI monitor.

Audio extraction.

Audio Extraction

Allows for integration with existing premium audio equipment via a 3.5mm phone jack or SPIDF (coaxial) connector, providing more flexibility for the installation.

Video layout.

Save/Load Your Scenes

Supports up to 10 sets of video layout. You can easily save and change a video layout, and restore it without configuring each input and output again.

Easy to install.

Installation-Friendly

Mountable with standard 1U (1+3⁄4 inches or 44.45 mm height) rack to be centrally managed in a cabinet.

Related Product - 4K 60Hz HDMI Repeater/Extender

4K 60Hz HDMI Repeater
HR01-4K6G

Model

HKM02BP-4K

HKM02B-4K

HKM02B

VDKM02B

Video Format

HDMI

HDMI

HDMI

VGA/DVI

Resolution

4K@30Hz

4K@30Hz

1080p@60Hz

1080p@60Hz

Audio Embed & Extract

V

V

V

V

IR

V

V

V

V

RS232

V

V

V

V

PoE

V

Fiber Module

V

V

  • Resolution up to 4K@60Hz 4:4:4.
  • Supports ARC (Audio Return Channel).
  • Supports HDMI audio extraction via S/PDIF coaxial output.
  • Supports cable locks on each HDMI input & output port.
  • Built-in LCM panel and LED indications for the status of all connected devices.
  • Rack-mountable (1U standard).
  • Managed via RS232, front panel buttons, IR remote, WebGUI,  iOS/Android APP.
HDMI Matrix Switch connection diagram.
Firmware/Software

Release Date

Ver.

Release Note

File Name

June 4, 2024

V1.0_2406041

Firmware Update
icon

Release Date

June 4, 2024

Ver.

V1.0_2406041

Firmware Update
icon
Tutorial Video

Show More
icon

Specification

ITEM NO.

HS10M-4K6G

Support

Compliance

HDMI 2.0, HDCP 2.2, DVI 1.1, 3D, HDR 10, Dolby Vision, HLG

Max. HDMI Resolution

4K@60Hz 4:4:4

Video Bandwidth

18 Gbps

Audio Format

LPCM 7.1@192KHz, Dolby TrueHD, DTS-HD MA

RS232 Baud Rate

9600 bps

IR Support

45°, 5M

Ports & Interfaces

Video Input

10 x HDMI Type A

Video Output

10 x HDMI Type A

Audio Output

2 x SPDIF

Ethernet Interface

1 x RJ45

RS232 Interface

1 x DB9 Female (Console)

IR Interface

1 x (3.5mm) Phone Jack

USB Interface

1 x USB-A (Firmware Update)

Show More
