SDI01F-12G

12G-SDI Fiber Extender with Loop out

  • 12G-SDI input compatible with 6G/3G/HD/SD
  • Power Input with locking design to prevent power interruption
  • Small, compact and easy to install
  • Multiple mounting options (Wall/Rack & Din-Rail)
Inquiry

As a manufacturer, we value the profit of our clients and do not have any online store. You can get the unpublished price from us through the inquiry button.

SEE other models
Inquiry

SDI01F-12G is an SDI over fiber extender that supports 12G-SDI, 6G-SDI, 3G-SDI, and more. It offers single-mode and multimode fiber options, with a tested extension distance of up to 2 kilometers. A compact SDI over fiber extender lets users handily install it in various television and broadcasting applications.

12G-SDI over Fiber Extender for Professional Broadcasting

12G-SDI over Fiber Extender for Professional Broadcasting

In the fields of broadcasting, television programs, music performances, and sports events where SDI is used as the primary video interface, employing a stable fiber optic extender can significantly improve the quality of SDI transmission in large-scale applications.

SDI01F-12G is an SDI over fiber extender that supports 12G-SDI, 6G-SDI, 3G-SDI, and more. It offers single-mode and multimode fiber options, with a tested extension distance of up to 2 kilometers. A compact SDI over fiber extender lets users handily install it in various television and broadcasting applications.

SDI over Fiber Extender supports HD/3G/6G/12G-SDI video over fiber extension for 2 km.
SDI01F-12G - Tx/Rx

SDI over Fiber Extender Application

In live broadcasting at large concerts, SDI cameras must be paired with long-distance extension equipment, such as a fiber optic extender, to ensure real-time display of stage performances on large screens.

12G-SDI over Fiber Extender application.

SDI over Fiber Extender Features

Supports Various SDI Formats

SDI01F-12G supports a maximum resolution of 12G-SDI, delivering the clearest image performance. It is also compatible with earlier SDI formats and diverse resolutions and frequencies, working with a wide range of new and old devices.

SDI Extender supports HD/3G/6G/12G-SDI and more SDI formats.
SDI Resolution Frequency
12G 4096 × 2160p 60/50.94/50/48/47.95/30/29.97/25/24/23.98 Hz
12G 3840 × 2160p 60/50.94/50/48/47.95/30/29.97/25/24/23.98 Hz
6G 4096 × 2160p 30/29.97/25/24/23.98 Hz
6G 3840 × 2160p 30/29.97/25/24/23.98 Hz
6G 2048 × 1080p 60/50.94/50/48/47.95 Hz
6G 1920 × 1080p 60/50.94/50/48/47.95 Hz
...and more

Extremely Long-Range SDI Extension

SDI01F-12G utilizes SFP fiber modules to achieve extremely long extension distances. The SDI over fiber extender uses a single-mode fiber to extend SDI for up to 10km and uses a multimode fiber for up to 400m, ideal for medium to long-distance transmission.

12G-SDI over Fiber Extender sends SDI signals for 10km over single-mode fiber optics and 400m over multimode fiber optics.

SDI Loop-out Function

SDI01F-12G features a loop at the transmission end, allowing users to monitor the live camera feed in real-time.

SDI loop at the transmitter end.

Secure Power Connector Design

SDI01F-12G's power connector features a threaded design, allowing the power cord to be securely connected to the device, minimizing the risk of disconnection. This significantly reduces the likelihood of image distortion or loss caused by an unstable power supply.

SDI extender with a secure BNC connector preventing accidental disconnection.

Multiple Installation Options

SDI01F-12G offers various mounting options, including din-rail, wall-mounting, and rack-mounting. This flexibility allows users to manage multiple audiovisual devices and setups efficiently.

SC&T SDI Converter Series

Learn more about SDI to HDMI Converter and HDMI to SDI Converter series.

In today's photography studios, broadcasting, and television production, the predominant interfaces are SDI and HDMI. There is often a need to use different interfaces interchangeably. SDI and HDMI converters facilitate smoother video transmission in such scenarios.

Model

HKM02BP-4K

HKM02B-4K

HKM02B

VDKM02B

Video Format

HDMI

HDMI

HDMI

VGA/DVI

Resolution

4K@30Hz

4K@30Hz

1080p@60Hz

1080p@60Hz

Audio Embed & Extract

V

V

V

V

IR

V

V

V

V

RS232

V

V

V

V

PoE

V

Fiber Module

V

V

  • 12G-SDI input compatible with 6G/3G/HD/SD
  • SMPTE 259, SMPTE 292-1, SMPTE 424, SMPTE 2081-1 and SMPTE 2082-1 compatible
  • 12G-SDI transmission distance up to 10km for single-mode fibers
  • Power input with locking design to prevent power interruption
  • Small, compact and easy to install
  • Multiple mounting options (Wall/Rack & Din-Rail)
12G-SDI over Fiber connection diagram.
